Key Points
- Real-time transmission over UTP CAT5E/6 cable.
- Passive, no need for power supply.
- With female BNC connector, and pluggable screw terminal connections.
Specification Details Model PFM800-E Transmission Signal 1 Channel Transmission Distance – 720P Max. 400 m (1312.34 ft) Transmission Distance – 1080P Max. 250 m (820.21 ft) Category Type UTP CAT 5E/6 Coaxial Video Connector BNC-M Twisted-Pair Video Connector Push-Terminal Compatible Format HDCVI / AHD / TVI / CVBS Resolution 720P / 1080P Anti-Interference >60 dB ESD Protection 1a Contact Discharge – Level 3; 1b Air Discharge – Level 3 Coaxial Cable Protection 2KV (Common-Mode), Per IEC1000-4-5 UTP Cable Protection 2KV (Differential-Mode), 4KV (Common-Mode), Per IEC1000-4-5 BNC Male Impedance 75 Ohms UTP Cable Impedance 100 Ohms Dimensions (L × W × H) 180 × 19 × 16 mm (7.09 × 0.75 × 0.63 in) Shell Material ABS Color Black Net Weight 42 g/pair (0.09 lb) MTBF >10,000 h Operating Temperature -10°C to +55°C (14°F to 131°F) Storage Temperature -20°C to +70°C (-4°F to 158°F) Humidity 0–95% RH, Non-Condensing
