Key Points
- 7-inch TFT Screen
- Metal VTO
- Video Intercom Function: Unlock, Voice Call, Video Call, Volume
- System Capacity: 2 Door Stations + 3 Indoor Monitors
- Multiple Bell Sounds
- Supports Digital Wide Dynamic Range (DWDR)
| Specification | Details |
|---|---|
| Model | DHI-VTH1020J-T |
| System | |
| Button Type | Touch button |
| Basic | |
| Display | 7.0″ TFT |
| Resolution | 1024 × 600 |
| Indicator Light | 1 indicator light; Green: Power on |
| Function | |
| Communication Method | Analog |
| Performance | |
| Casing | PC + ABS |
| General | |
| Color | White |
| Power Supply | DC 12V/1A |
| Power Adapter | Included |
| Installation | Surface mount |
| Certifications | CE/FCC |
| Accessory | Bracket (included); 5 m (16.40 ft) cable (included) |
| Dimensions | 133.90 mm × 182.70 mm × 17.70 mm (5.27″ × 7.19″ × 0.70″) |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F) |
| Operating Humidity | 10%RH–95%RH |
| Power Consumption | ≤ 2W (standby); ≤ 5W (working) |
| Net Weight | 0.25 kg (0.55 lb) |
| Gross Weight | 0.48 kg (1.05 lb) |
| Model | DHI-VTO1000JM |
| System | |
| Button Type | Mechanical |
| Basic | |
| Camera | 1/4″ 1.3 MP CMOS |
| Field of View | Horizontal: 70°; Vertical: 40° |
| WDR | DWDR |
| Illuminator Type | Auto IR |
| Day/Night | ICR auto switch |
| Audio Input | 1 channel to the microphone; pickup distance 0.5 m |
| Audio Output | 1 channel to the speaker |
| Indicator Light | 1 indicator light; Green: Power on |
| Function | |
| Communication Method | Analog |
| Unlock Mode | Remote unlock |
| Performance | |
| Casing | ADC12 |
| Port | |
| Unlock Button | 1 |
| Door Status Detection | 1 |
| General | |
| Color | Black |
| Power Supply | Powered by indoor monitor |
| Installation | Surface mount |
| Certifications | CE/FCC |
| Accessory | Rain cover (included); 5 m cable (included in kit) |
| Dimensions | 131.45 mm × 46.00 mm × 33.80 mm (5.18″ × 1.81″ × 1.33″) |
| Protection Grade | IK07; IP66 (Apply silicon sealant to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) |
| Operating Temperature | -30°C to +60°C (-22°F to +140°F) |
| Operating Humidity | 10%RH–95%RH |
| Power Consumption | ≤ 1W (standby); ≤ 3W (working) |
| Net Weight | 0.18 kg (0.40 lb) |
| Gross Weight | 0.40 kg (0.84 lb) |
