Key Points
- One-Click Help
- Built-In High-Sensitivity Microphone with Clear Sound and 2 Speakers
- Supports Audio Broadcast and Group Broadcast
- PoE Power Supply
- Supports 12V/1A Power Output
- IP65 & IK10
- 4MP Low-Illumination CMOS Camera and Starlight Image Sensor
- Supports Recording Videos, Capturing Snapshots and Configuring The Pre-Recording Time
| Specification | Details |
|---|---|
| System | |
| Main Processor | Embedded Processor |
| Operating System | Embedded Linux OS |
| Button Type | Mechanical |
| Network Protocol | UDP; TCP; IPv4; RTSP; SIP; P2P; RTP |
| Basic | |
| Camera | 4MP CMOS high-definition, low illumination, cameras |
| Field of View | H: 104°; V: 57°; D: 113° |
| Video Compression | H.264; H.265 |
| Video Resolution | Main stream: 1080p (up to 2512 × 1408);Sub stream: 1280 × 720 |
| Video Bit Rate | 224 Kbps–12 Mbps |
| Light Compensation | Auto IR |
| Day/Night | Auto(ICR)/Color/B/W |
| Audio Compression | G.711a; G.711Mu; G.711u; PCM; MP3; G726 |
| Audio Input | Built-in dual-way silicon microphone, external 3.5 mm audio input |
| Audio Output | Built-in dual speaker, external active speaker |
| Audio Mode | Two-way audio |
| Audio Enhancement | Echo suppression/digital noise reduction |
| Audio Bit Rate | 16 KHz, 16 Bit |
| Function | |
| Communication Mode | Full digital |
| Auto Snapshot | Yes |
| Storage | Micro SD Card, max 64 GB |
| Performance | |
| Casing Material | Aluminum alloy |
| Port | |
| RS-485 | 1 |
| Alarm Input | 2 |
| Alarm Output | 2 |
| Power Output | 2 (12 V/1 A; 12 V/200 mA) |
| Network Port | 2 × 10 M/100 M ports |
| Alarm | |
| Tamper Alarm | Yes |
| General | |
| Appearance Color | Silver |
| Power Supply | 12 VDC, 3 A; Standard PoE |
| Power Adapter | Optional |
| Installation | Flush Mount |
| Certifications | CE |
| Accessory | Flush mount box (optional) |
| Product Dimensions | 210.0 mm × 140.0 mm × 42.0 mm (8.3″ × 5.5″ × 1.7″) |
| Protection | IP65; IK10 |
| Operating Temperature | –30 °C to +60 °C (-22 °F to +140 °F) |
| Operating Humidity | 10%–90% (RH), non-condensing |
| Operating Environment | Outdoor |
