| System |
|
| Main Processor |
Embedded Processor |
| Operating System |
Embedded Linux OS |
| Button Type |
Touch Button |
| Interoperability |
CGI / ONVIF |
| Network Protocol |
TCP / RTMP / HTTP/HTTPS / DNS / RTSP / ONVIF / SIP / RTP |
| Basic |
|
| Screen Type |
Capacitive Touchscreen |
| Display Screen |
8-inch Display Screen |
| Screen Resolution |
800 (H) × 1280 (V) |
| Camera |
1/2.8″ 2MP CMOS High-Definition, Low Illumination, Dual Cameras |
| Field of View |
H: 95° / V: 50° / D: 110° |
| WDR |
120 dB |
| Noise Reduction |
3D NR |
| Video Compression |
H.264 / H.265 |
| Video Resolution |
Main Stream: 720P / D1 / WVGA; Sub Stream: 1080P / 720P / D1 / WVGA / CIF / QVGA |
| Video Frame Rate |
25 fps |
| Video Bit Rate |
1,024–8,192 kbps |
| Light Compensation |
Auto White Light |
| Audio Compression |
G.711a / G.711u / PCM |
| Audio Input |
1 Channel |
| Audio Output |
Built-in Speaker |
| Audio Mode |
Two-way Audio |
| Audio Enhancement |
Echo Suppression / Digital Noise Reduction |
| Audio Bit Rate |
16 kHz, 16 bit |
| Function |
|
| Communication Mode |
Full Digital |
| Verification Method |
Fingerprint / Remote / Face Recognition / Card / Password |
| Auto Snapshot |
Yes |
| Information Release |
Receive and view text information released by the management center |
| Leave Videos |
Yes (SD card required in the indoor monitor or door station) |
| Storage |
Micro SD Card, up to 512 GB |
| Web Configuration |
Yes |
| Auto Registration |
Yes |
| RFID |
|
| Card Type |
IC Card |
| Performance |
|
| Card Reading Distance |
0–4 cm (IC Card) |
| Issue Card Locally |
Yes |
| Face Recognition Height Range |
1.1–2.2 m (3.61–7.22 ft) |
| Face Recognition Distance |
0.3–2.0 m (0.98–6.56 ft) |
| Face Recognition Accuracy |
99.9% |
| Face Recognition Time |
0.2 sec |
| Fingerprint Sensor Type |
Capacitive |
| Fingerprint Comparison Time |
≤1.5 sec |
| Fingerprint Recognition Time |
≤1 sec |
| Casing Material |
Metal |
| Capacity |
|
| Card Capacity |
50,000 |
| Face Image Capacity |
50,000 |
| Fingerprint Capacity |
10,000 |
| Port |
|
| RS-485 |
1 |
| Wiegand |
1 (Configurable as Input or Output) |
| Alarm Input |
2 Channels |
| Alarm Output |
2 Channels |
| Power Output |
1 Port (12 V, 500 mA) |
| Exit Button |
1 Channel |
| Door Status Detection |
1 Channel |
| Lock Control |
1 Channel, Open by Default |
| Network Port |
1 × 10/100 Mbps Ethernet Port |
| Alarm |
|
| Tamper Alarm |
Yes |
| General |
|
| Unlock Password Mode |
User, Public and Duress Passwords |
| Appearance Color |
Silver |
| Power Supply |
12 VDC, 3 A; Standard PoE |
| Power Adapter |
Optional |
| Installation |
Flush Mount / Wall Mount |
| Certifications |
CE |
| Accessories |
Power Supply (Optional); Flush Mount Box (Optional) |
| Product Dimensions |
389 × 145 × 43.5 mm (15.31 × 5.70 × 1.71 in) |
| Protection |
IP65 Rated (Silicone Sealant Required) |
| Operating Temperature |
–30°C to +60°C (–22°F to +140°F) |
| Operating Humidity |
0%–90% RH, Non-Condensing |
| Operating Altitude |
0–1,300 m (0–4,265.09 ft) |
| Power Consumption |
≤5 W (Standby), ≤18 W (Working) |
| Gross Weight |
1.91 kg (4.21 lb) |
