Key Points
- 10-inch Colorful TFT, resolution: 1024 × 600
- Standard PoE
- Embedded 8GB SD Card
- Device Port: 6-Channel Alarm Input, 1-Channel Alarm Output, 1-Channel RS485
| Specification | Details |
|---|---|
| System Parameter | |
| Operating System | Embedded LINUX operating system |
| Network Protocol | IPv4, FTP, RTSP, RTP, TCP, UDP, SIP |
| Keyboard Type | Touch keyboard (0–9, *, #) |
| Basic Parameter | |
| Screen Type | Capactive screen |
| Display | 10-inch TFT LCD |
| Resolution | 1024 (H) × 600 (V) |
| Video Compression | H.264 |
| Audio Compression | G.711a, G.711Mu, G.711u, PCM |
| Audio Input | 1 channel all-direction microphone |
| Audio Output | 1 channel |
| Audio Mode | Support dual-way bidirectional talk |
| Audio Enhancement | Support echo suppression/DNR |
| Function Parameter | |
| Communication Mode | Full digital |
| Leave Videos or Text Messages | Support |
| DND Mode | Support |
| Sub-station Quantity | 9 |
| Edge Storage | Embedded 8 GB |
| Port | |
| Alarm Input | 6 channels |
| Alarm Output | 1 channel |
| Doorbell | Supported by every channel |
| Network | 1 RJ-45, 10 M/100 Mbps self-adaptive |
| Alarm Parameter | |
| SOS Alarm | Support |
| General Parameter | |
| Casing | PC+ABS |
| Appearance Color | Black |
| Power Supply | Standard PoEDC 12V 1A |
| Power | Optional |
| Installation | Surface |
| Certifications | CE/FCC |
| Dimensions | 260 mm × 170 mm × 28 mm (10.24″ × 6.69″ × 1.10″) |
| Operating Temperature | -10°C to +55°C (+14°F to +131°F ) |
| Operating Humidity | 10%RH–90%RH (No condensation) |
| Power Consumption | ≤7W (Work) |
