| System (VTO) |
Main Processor |
Embedded Processor |
|
Operating System |
Embedded Linux Operation System |
|
Button Type |
Mechanical |
|
Interoperability |
ONVIF; CGI |
|
Network Protocol |
SIP; TCP; RTP; UPnP; P2P; DNS; UDP; RTSP; IPv4 |
| Basic (VTO) |
Camera |
1/2.9″ 2 MP CMOS |
|
Field of View |
H: 168.6°; V: 87.1°; D: 176.7° |
|
WDR |
120 dB |
|
Noise Reduction |
3D NR |
|
Video Compression |
H.265; H.264 |
|
Video Resolution |
Main stream: 720p; WVGA; D1; CIFSub stream: 1080p; WVGA; D1; QVGA; CIF |
|
Video Frame Rate |
25 fps |
|
Video Bit Rate |
256 kbps to 8 Mbps |
|
Light Compensation |
Auto IR |
|
Day/Night |
Auto(ICR)/Color/B/W; Color/B/W |
|
Audio Compression |
G.711a; G.711u; PCM |
|
Audio Input |
1 channel |
|
Audio Output |
Built-in speaker |
|
Audio Mode |
Two-way audio |
|
Audio Enhancement |
Echo suppression/digital noise reduction |
|
Audio Bit Rate |
16 kHz, 16 bits |
| Function (VTO) |
Communication Mode |
Full digital |
|
Unlock Mode |
Remote |
|
Leave Videos |
Yes (SD card is inserted in the indoor monitor or door station) |
|
Storage |
Supports Micro SD card (up to 256 GB) |
|
Web Configuration |
Yes |
| Performance (VTO) |
Casing Material |
Aluminum |
| Port (VTO) |
RS-485 |
1 |
|
Alarm Output |
1 |
|
Power Output |
1 port (12 V, 600 mA) |
|
Exit Button |
1 |
|
Door Status Detection |
1 |
|
Lock Control |
1 |
|
Network Port |
1 × RJ-45 port, 10/100 Mbps network port |
| Alarm (VTO) |
Tamper Alarm |
Yes |
| General (VTO) |
Appearance Color |
Silver |
|
Power Supply |
48 VDC, 0.4 A;PoE (802.3af/at) |
|
Power Adapter |
Optional |
|
Installation |
Surface mount (The surface mount kit comes with the surface mount bracket) |
|
Certifications |
CE |
|
Product Dimensions |
200.0 mm × 98.0 mm × 35.4 mm (7.87″ × 3.86″ × 1.39″) |
|
Protection |
IK08, IP65 (Silicone sealant is needed, see the quick start guide) |
|
Operating Temperature |
–40 °C to +60 °C (–40 °F to +140°F) |
|
Operating Humidity |
10%–95% (RH), non-condensing |
|
Operating Altitude |
Beneath 3000 m (9842.52 ft) |
|
Operating Environment |
Outdoor |
|
Power Consumption |
≤5 W (standby), ≤7 W (working) |
|
Gross Weight |
692 g (1.53 lb) |
|
Storage Humidity |
30%–75% (RH) |
|
Storage Temperature |
0 °C to +40 °C (+32 °F to +104 °F) |
| System (VTH) |
Main Processor |
Embedded Processor |
|
Operating System |
Embedded Linux Operation System |
| Basic (VTH) |
Screen Type |
Capacitive Touchscreen |
|
Display Screen |
7″ TFT |
|
Screen Resolution |
1024 (H) × 600 (V) |
|
Audio Compression |
G.711a; G.711u; PCM |
|
Audio Input |
1-channel all-direction microphone |
|
Audio Output |
Built-in 1.5 W loudspeaker |
|
Audio Mode |
Two-way audio |
|
Audio Enhancement |
Echo suppression/digital noise reduction |
|
Audio Bit Rate |
16 kbps |
| Function (VTH) |
Communication Mode |
Full digital |
|
Information Release |
Supports to receive and view notifications issued by center |
|
Leave Videos |
Yes |
|
DND Mode |
Do not disturb period can be set |
|
Number of Extensions |
9 |
|
Storage |
Embedded 8 GB card |
| Port (VTH) |
Alarm Input |
6 channel (switch quantity) |
|
Alarm Output |
1 channel |
|
Network Port |
1 × RJ-45 port |
| Alarm (VTH) |
SOS Alarm |
Yes |
| Performance (VTH) |
Casing Material |
PC + ABS |
| General (VTH) |
Appearance Color |
Black |
|
Power Supply |
12 VDC, 1 A, PoE |
|
Installation |
Surface Mount |
|
Certifications |
CE; FCC; UL |
|
Accessory |
Default bracket; Default alarm cable |
|
Product Dimensions |
119.6 mm × 221.5 mm × 23.5 mm (4.71″ × 8.72″ × 0.93″) |
|
Operating Temperature |
-10°C to +55°C (+14°F to +131°F) |
|
Operating Humidity |
10%-95% (RH), non-condensing |
|
Operating Altitude |
0 m–3,000 m (0 ft–9,842.52 ft) |
|
Operating Environment |
Indoor |
|
Power Consumption |
≤4 W (standby), ≤6 W (working) |
|
Gross Weight |
0.35 kg (0.77 lb) |
|
Storage Temperature |
0 °C to +40 °C (+32 °F to +104 °F) |
|
Storage Humidity |
30%–75% (RH), non-condensing |
| System (Networking Device) |
Main Processor |
Embedded Processor |
| Port (Networking Device) |
Network Port |
4 × PoE ports with 10/100 Mbps Base-TX2 × uplink ports with 10/100 Mbps Base-TX |
| General (Networking Device) |
Appearance Color |
Black |
|
Power Supply |
Built-in power supply: 100–240 VAC |
|
Certifications |
CE; FCC |
|
Product Dimensions |
194.0 mm × 108.1 mm × 35.0 mm (7.64″ × 4.26″ × 1.38″) |
|
Operating Temperature |
–10 °C to +55 °C (+14 °F to +131 °F) |
|
Operating Humidity |
10%–90% (RH), non-condensing |
|
Power Consumption |
Idling: 0.5 W; Full load: 36 W |
|
Gross Weight |
1.11 kg (2.15 lb) |
