| System |
|
| Main Processor |
Embedded Processor |
| Button Type |
Touch button |
| Network Protocol |
IPv4; RTSP; UDP; P2P; RTP; TCP; SIP |
| OSDP Protocol |
Yes |
| Interoperability |
ONVIF; CGI |
| SDK and API |
Yes |
| Basic |
|
| Product Type |
Standalone |
| Display Screen |
4.3-inch display screen |
| Screen Type |
Capacitive Touchscreen |
| Screen Resolution |
480 (H) × 800 (V) |
| Camera |
2-MP CMOS HD dual-lens camera |
| WDR |
DWDR |
| Light Compensation |
Auto IR |
| Voice Prompt |
Yes |
| Speaker |
Yes |
| Casing Material |
PC + GF |
| Function |
|
| Verification Method |
Card; Password; Remote; QR Code; Face Recognition |
| Door Open Notification Mode |
Quick mode; Simple mode; Standard mode; Comparison mode |
| Period List |
128 periods |
| Holiday Period |
128 periods |
| Network Update |
Yes |
| First User Unlock |
Yes |
| Remote Verification |
Yes |
| Restricted List/Trusted List |
Yes |
| Advertisement Playing |
Plays advertisements in video and image format |
| Peripheral Card Reader |
1 × RS-485 card reader; 1 × Wiegand card reader |
| Multi-user Authentication |
Yes |
| Real-time Monitoring |
Yes |
| Multi-factor Authentication |
Yes |
| Capture Function |
Yes |
| Web Configuration |
Yes |
| Auto Registration |
Yes |
| RFID |
|
| Card Type |
IC card; Desfire card (EV3, Compatible with Dahua card by default) |
| Modulation Type |
ASK |
| Frequency Range |
13.56 MHz |
| Max. Transmission Power |
42 dBuA/m @ 10 m |
| Network |
|
| Max. Transmission Power |
≤20 dBm @ 2400–2483.5 MHz |
| Wi-Fi |
Yes |
| Wireless Standard |
IEEE 802.11b/802.11g/802.11n |
| Wireless Frequency Range |
2.4 GHz |
| Performance |
|
| Card Reading Distance |
0 cm–3 cm (0″–1.18″) |
| Face Recognition Height Range |
1.1 m–2.0 m (3.61 ft–6.56 ft) |
| Face Recognition Distance |
0.3 m–1.5 m (0.98 ft–4.92 ft) |
| Face Recognition Accuracy |
99.9% |
| Face Recognition Time |
0.2 s |
| User |
|
| User (Card) Type |
Normal user; VIP users; patrol users; guest user; blocklist user; other user; custom user 1; custom user 2 |
| Capacity |
|
| Face Image Capacity |
6,000 |
| User Capacity |
6,000 |
| Card Capacity |
10,000 |
| Password Capacity |
6,000 |
| Record Capacity |
300,000 |
| Port |
|
| RS-485 |
1 |
| Wiegand |
1 |
| USB |
1 |
| Network Port |
1 × RJ-45 10/100 Mbps self-adaptive Ethernet port |
| Alarm Input |
1 |
| Alarm Output |
1 |
| Alarm Linkage |
Yes |
| Exit Button |
1 |
| Door Status Detection |
1 |
| Lock Control |
1 |
| Power Output Port |
1 |
| Alarm |
|
| Anti-pass Back |
Yes |
| Tamper Alarm |
Yes |
| Duress Alarm |
Yes |
| Door Sensor Timeout |
Yes |
| Intrusion |
Yes |
| Illegal Card Exceeding Threshold |
Yes |
| General |
|
| Power Adapter |
Included |
| Power Supply |
Standard PoE; 12 VDC, 2 A |
| Protection |
IP65 |
| Power Consumption |
≤24 W |
| Product Dimensions |
180.1 mm × 90.1 mm × 27.0 mm (7.09″ × 3.55″ × 1.06″) (L × W × H) |
| Packaging Dimensions |
268 mm × 136 mm × 78 mm (10.55″ × 5.35″ × 3.07″) (L × W × H, in an inner carton); 590 mm × 432 mm × 302 mm (23.23″ × 17.01″ × 11.89″) (L × W × H, protection box) |
| Transport Package Dimensions |
590 mm × 432 mm × 302 mm (23.23″ × 17.01″ × 11.89″) (L × W × H, protection box) |
| Operating Temperature |
–30 °C to +45 °C (–22 °F to +113 °F) |
| Operating Humidity |
0%–90% (RH), non-condensing |
| Operating Altitude |
0 m–1,300 m (0 ft–4265.09 ft) |
| Operating Environment |
Indoor; Outdoor |
| Gross Weight |
0.70 kg (1.54 lb) |
| Accessory |
Wall mount bracket (included) |
| Installation |
Wall Mount; Surface Mount; Desk Mount; Turnstile Mount; 86 mm Junction Box Mount |
| Storage Temperature |
–20 °C to +70 °C (–4 °F to +158 °F) |
| Storage Humidity |
30%–75% |
