Power and Connectivity Features
Audio Interface
G.711A, G.711U, PCM
Alarm Interface
Motion detection
Other Connectivity Features
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Power Requirement
Max 2.6W (12V DC, WLED on)
Power Consumption
4 W
Other Power Features
12 VDC ± 30%
In the Box
1 home security camera
General
Brand
CP PLUS
Model Number
CP-URC-DC51PL3C-L-V2
Type
Indoor Security Camera
Product Type
Standalone
Number of Channels
1
Camera Type
5 MP Illumax (B/C D/C)
Video Output
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Video Recording Resolution
4M (2560 × 1440), 2M (1920 × 1080); 960H (960 × 576/960 × 480)
Video Recording Frame Rate
CVI: PAL: 5M@25 fps, 4M@25 fps, 2M@25 fps, NTSC: 5M@25 fps, 4M@30 fps, 2M@30 fps AHD: PAL: 4M@25 fps, NTSC: 4M@30 fps TVI: PAL: 4M@25 fps, NTSC: 4M@30 fps CVBS: PAL: 960H, NTSC: 960H
Additional Features
Alarm Action
Human Body Detection Support the classification and accurate detection of human & Motor Vehicle
Mobile Compatibility
yes
Application Support
Mobile Software: iCMOB, gCMOB, CMS Software: KVMS Pro Lite
Operating Temperature
–40 °C to +55 °C (–40 °F to +131 °F) degree C
Material
Plastic
Model Name
5MP Dual Light Dome Camera – 30Mtr.(CP-URC-DC51PL3C-L-V2)
Color
White
Lens Size
3.6 mm
Angle of View
105 degree
Mounting Type
Wall Mount
Key Features
Hd Camera, Night Color Camera, Color With Audio, CP PLUS
Other Features
<95% (RH), non-condensing
Dimensions
Width
85 mm
Height
771 mm
Weight
11 g
Product Details
Video Formats
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Recording Formats
CVI: PAL: 1080p@25 fps NTSC: 1080p@30 fps AHD: PAL: 1080p@25 fps NTSC: 1080p@30 fps TVI: PAL: 1080p@25 fps NTSC: 1080p@30 fps CVBS: PAL: 960H NTSC: 960H
Display Frame Rate
25/30fps
Record Modes
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Other Video Features
Close Focus Distance 3.6 mm: 1.3 m, 2.8 mm: 1.0 m, 6 mm: 2.8 m
Image Sensor
5MP PS CMOS Image Sensor
Shutter Type
1/25 s–1/100000 s/ NTSC: 1/30 s–1/100000 s
Image Resolution
2880 (H) × 1620 (V)
IR Distance
30 m
Number of IR LEDs
2
Other Camera and Imaging Features
3.6 mm: Detect: 76.0 Mtr., Observe: 30.4 Mtr., Recognize: 15.2 Mtr., Identify : 7.6 Mtr. 2.8 mm: Detect:66.0 mtr., Observe: 26.4 Mtr., Recognize: 13.2 Mtr., Identify: 13.2 Mtr., Day/Night Auto(ICR)/Color/B/W, IR Mode Smart IR&WL, WL Mode, IR Mode
HDD Available
No
HDD Type
N/A
Compatible Devices
Monitor
Power Source
DC
Remote Connectivity
Cloud
Remote Pan & Tilt
Pan & Tilt
Storage Type
HDD
USB Port Present
No
Cry Detection Sensor
Yes
Horizontal View Range
30 m
Camera Resolution
5 mp
HDD Capacity
N/A
Night Vision
Yes
Maximum Record Time
24 hr
Remote Control
Yes
