Face Recognition Access Controller
Key Points
- Visible Light Facial Recognition and Liveness Detection
- 6,000 Faces, 6,000 Fingerprints, 10,000 Cards and 6,000 Passwords
- 2-MP CMOS Dual-lens Camera, DWDR
- 4.3-inch Touch Screen with Resolution of 272 × 480
- Face Recognition Duration< 0.2s/person, Accuracy rate ≥ 99.9%
- Supports Video Intercom,Time Attendance and Advertisement Playback
- Easy Configuration via PC and Mobile Web Client
- IP65 Protection
| Category | Specification | Details |
|---|---|---|
| System | Main Processor | Embedded Processor |
| Button Type | Touch button | |
| Network Protocol | UDP; TCP; IPv4; RTSP; SIP; P2P; RTP | |
| OSDP Protocol | Yes | |
| Interoperability | CGI; ONVIF | |
| SDK and API | Yes | |
| Basic | Product Type | Standalone |
| Display Screen | 4.3″ LCD | |
| Screen Type | Capacitive Touchscreen | |
| Screen Resolution | 272 (H) × 480 (V) | |
| Camera | 2-MP CMOS HD dual-lens camera | |
| WDR | DWDR | |
| Light Compensation | Auto IR | |
| Voice Prompt | Yes | |
| Buzzer | Yes | |
| Casing Material | PC+GF | |
| Function | Unlock Mode | Fingerprint, Card, remote, password, QR code, face and combination unlock |
| Card Type | ID cards | |
| Period List | 128 periods | |
| Holiday Period | 128 periods | |
| Network Update | Yes | |
| First User Unlock | Yes | |
| Remote Verification | Yes | |
| Restricted List / Trusted List | Yes | |
| Advertisement Playing | Plays advertisements in video and image format | |
| Peripheral Card Reader | 1 × RS-485 card reader; 1 × Wiegand card reader | |
| Multi-user Authentication | Yes | |
| Real-time Monitoring | Yes | |
| Multi-factor Authentication | Yes | |
| Capture Function | Yes | |
| Web Configuration | Yes | |
| Auto Registration | Yes | |
| RFID | Modulation Type | ASK |
| Frequency Range | 125 kHz | |
| Max. Transmission Power | 66 dBuA/m @ 10 m | |
| Performance | Card Reading Distance | 0 cm–3 cm (0″–1.18″) |
| Face Recognition Height Range | 1.1 m–2.0 m (3.61 ft–6.56 ft) | |
| Face Recognition Distance | 0.3 m–1.5 m (0.98 ft–4.92 ft) | |
| Face Recognition Accuracy | 99.9% | |
| Face Recognition Time | 0.2 s | |
| Fingerprint Verification Mode | 1:N | |
| User | User (Card) Type | Normal user; VIP users; patrol users; guest user; blocklist user; other user; custom user 1; custom user 2 |
| Capacity | User Capacity | 6,000 |
| Face Image Capacity | 6,000 | |
| Fingerprint Capacity | 6,000 | |
| Card Capacity | 10,000 | |
| Password Capacity | 6,000 | |
| Record Capacity | 300,000 | |
| Port | RS-485 | 1 |
| Wiegand | 1 | |
| USB | 1 | |
| Network Port | 1 × RJ-45 10/100 Mbps self-adaptive Ethernet port | |
| Alarm Input | 1 | |
| Alarm Output | 1 | |
| Alarm Linkage | Yes | |
| Exit Button | 1 | |
| Door Status Detection | 1 | |
| Lock Control | 1 | |
| Alarm | Anti-pass Back | Yes |
| Tamper Alarm | Yes | |
| Duress Alarm | Yes | |
| Door Sensor Timeout | Yes | |
| Intrusion | Yes | |
| Illegal Card Exceeding Threshold | Yes | |
| Duress Fingerprint | Yes | |
| General | Power Adapter | Included |
| Power Supply | 12 VDC, 1.5 A | |
| Protection | IP65 | |
| Power Consumption | ≤12 W | |
| Product Dimensions | 180.1 mm × 90.1 mm × 27.0 mm (7.09″ × 3.55″ × 1.06″) (L × W × H) | |
| Packaging Dimensions | 268 mm × 136 mm × 78 mm (10.55″ × 5.35″ × 3.07″) (L × W × H, inner carton); 590 mm × 432 mm × 302 mm (23.23″ × 17.01″ × 11.89″) (L × W × H, protection box) | |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) | |
| Operating Humidity | 0%–90% RH, non-condensing | |
| Operating Altitude | 0 m–1,300 m (0 ft–4,265.09 ft) | |
| Operating Environment | Outdoor; Indoor | |
| Gross Weight | 0.70 kg (1.54 lb) | |
| Accessory | Wall mount bracket (included) | |
| Installation | Turnstile mount; 86 case mount; wall mount; surface mount |
