| System |
|
| Main Processor |
Embedded Processor |
| Button Type |
Mechanical |
| Network Protocol |
IPv4; RTSP; UDP; P2P; IPv6; RTP; TCP |
| OSDP Protocol |
Yes |
| Interoperability |
ONVIF; CGI |
| SDK and API |
Yes |
| Basic |
|
| Product Type |
Standalone |
| Display Screen |
2.4-inch display screen |
| Screen Type |
Non-touchscreen |
| Screen Resolution |
320 (H) × 240 (V) |
| Camera |
2 MP CMOS HD Dual Cameras |
| WDR |
DWDR |
| Light Compensation |
Auto IR |
| Voice Prompt |
Yes |
| Speaker |
Yes |
| Casing Material |
PC + ABS |
| Function |
|
| Verification Method |
Card/remote/password/face unlock |
| Card Type |
ID card |
| Period List |
128 periods |
| Holiday Period |
128 periods |
| Network Update |
Yes |
| First User Unlock |
Yes |
| Remote Verification |
Yes |
| Restricted List/Trusted List |
Yes |
| Wi-Fi |
Yes |
| Wireless Standard |
IEEE802.11b/802.11g/802.11n |
| Wireless Frequency Range |
2.4G |
| Peripheral Card Reader |
One RS-485 card reader or one Wiegand card reader |
| Multi-user Authentication |
Yes |
| Real-time Monitoring |
Yes |
| Multi-factor Authentication |
Yes |
| Capture Function |
Yes |
| Web Configuration |
Yes |
| Auto Registration |
Yes |
| Performance |
|
| Card Reading Distance |
0 cm–3 cm (0″–1.18″) |
| Face Recognition Height Range |
1.2 m–2.0 m (3.94 ft–6.56 ft) |
| Face Recognition Distance |
0.3 m–1.5 m (0.98 ft–4.92 ft) |
| Face Recognition Accuracy |
99.9% |
| Face Recognition Time |
0.2 s |
| User |
|
| User (Card) Type |
Common users, VIP users, patrol users, visitor users, blocklist users, other users, custom users 1 and custom users 2 |
| Capacity |
|
| User Capacity |
1000 |
| Face Image Capacity |
1000 |
| Card Capacity |
3000 |
| Password Capacity |
1000 |
| Record Capacity |
100000 |
| Port |
|
| RS-485 |
1 port (reuse the Wiegand port) |
| Wiegand |
1 port (reuse the RS-485 port) |
| USB |
1 × USB 2.0 port |
| Network Port |
1 × 10/100 Mbps Ethernet port |
| Doorbell |
1 |
| Exit Button |
1 |
| Door Status Detection |
1 |
| Lock Control |
1 |
| Power Output Port |
1 (12 V, 1.0 A) |
| Alarm |
|
| Anti-pass Back |
Yes |
| Tamper Alarm |
Yes |
| Duress Alarm |
Yes |
| Door Sensor Timeout |
Yes |
| Intrusion |
Yes |
| Illegal Card Exceeding Threshold |
Yes |
| General |
|
| Power Adapter |
Optional |
| Power Supply |
12 VDC, 2 A |
| Power Consumption |
≤12 W |
| Product Dimensions |
184.9 mm × 76.2 mm × 20.5 mm (7.28″ × 3.00″ × 0.81″) (H × W × D) |
| Packaging Dimensions |
219 mm × 122 mm × 58 mm (8.62″ × 4.80″ × 2.28″) (H × W × D) |
| Transport Package Dimensions |
219 mm × 122 mm × 58 mm (8.62″ × 4.80″ × 2.28″) (H × W × D) |
| Operating Temperature |
–10 °C to +45 °C (+14 °F to +113 °F) |
| Operating Humidity |
0%–90% (RH), non-condensing |
| Operating Altitude |
0 m–1,300 m (0 ft–4,265.09 ft) |
| Operating Environment |
Indoor |
| Gross Weight |
0.6 kg (1.32 lb) |
| Accessory |
Wall mount bracket (included) |
| Installation |
Wall Mount |
| Storage Temperature |
–20 °C to +70 °C (–4 °F to +158 °F) |
| Storage Humidity |
30%–75% |
